Olympus E-5 Specifications - Olympus E-5 Sample photos - Explore a collection of sample images captured with the Olympus E-5.
| Body type | ||
|---|---|---|
| Body type | Mid-size SLR | |
| Sensor | ||
| Max resolution | 4032 x 3024 | |
| Other resolutions | 3200 x 2400, 2560 x 1920, 1600 x 1200, 1280 x 960, 1024 x 960, 640 x 480 | |
| Image ratio w:h | 4:3, 16:9 | |
| Effective pixels | 12 megapixels | |
| Sensor photo detectors | 13 megapixels | |
| Sensor size | Four Thirds (17.3 x 13 mm) | |
| Sensor type | CMOS | |
| Processor | TruePic V+ | |
| Image | ||
| ISO | Auto (200-6400), 100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1600, 2000, 2500, 3200, 6400 | |
| White balance presets | 8 | |
| Custom white balance | Yes (4) | |
| Image stabilization | Sensor-shift | |
| Uncompressed format | RAW | |
| JPEG quality levels | Superfine, Fine, Normal, Basic | |
| Optics & Focus | ||
| Autofocus |
|
|
| Digital zoom | No | |
| Manual focus | Yes | |
| Number of focus points | 11 | |
| Lens mount | Four Thirds | |
| Focal length multiplier | 2× | |
| Screen / viewfinder | ||
| Articulated LCD | Fully articulated | |
| Screen size | 3″ | |
| Screen dots | 920,000 | |
| Touch screen | No | |
| Screen type | HyperCrystal transmissive LCD | |
| Live view | Yes | |
| Viewfinder type | Optical (pentaprism) | |
| Viewfinder coverage | 100% | |
| Viewfinder magnification | 1.15× (0.57× 35mm equiv.) | |
| Photography features | ||
| Minimum shutter speed | 60 sec | |
| Maximum shutter speed | 1/8000 sec | |
| Aperture priority | Yes | |
| Shutter priority | Yes | |
| Manual exposure mode | Yes | |
| Subject / scene modes | Yes | |
| Built-in flash | Yes (Pop-up) | |
| Flash range | 18.00 m (at ISO 200) | |
| External flash | Yes (Hot-shoe, Wireless plus sync connector) | |
| Flash modes | Auto, On, Off, Red-Eye, Slow Sync, Fill-in | |
| Continuous drive | 5.0 fps | |
| Self-timer | Yes (2 or 12 sec) | |
| Metering modes |
|
|
| Exposure compensation | ±5 (at 1/3 EV, 1/2 EV, 1 EV steps) | |
| AE Bracketing | (2, 3, 5, 7 frames at 1/7 EV, 1/5 EV, 1/3 EV, 1 EV steps) | |
| WB Bracketing | Yes (3 frames in 2, 4, 6 steps) | |
| Videography features | ||
| Resolutions | 1280 x 720 (30 fps), 640 x 480 (30 fps) | |
| Format | Motion JPEG | |
| Microphone | Stereo | |
| Speaker | None | |
| Storage | ||
| Storage types | Compact Flash (Type I or II)/SD/SDHC/SDXC | |
| Storage included | None | |
| Connectivity | ||
| USB |
USB 2.0 (480 Mbit/sec) |
|
| HDMI | Yes (Mini HDMI type-C) | |
| Remote control | Yes (Optional RM-1) | |
| Physical | ||
| Environmentally sealed | Yes (Weather and dust resistant) | |
| Battery | Battery Pack | |
| Battery description | BLM-5 Lithium-Ion rechargeable battery | |
| Battery Life (CIPA) | 870 | |
| Weight (inc. batteries) | 800 g (1.76 lb / 28.22 oz) | |
| Dimensions | 143 x 117 x 75 mm (5.63 x 4.61 x 2.95″) | |
| Other features | ||
| Orientation sensor | Yes | |
| GPS | None | |
